Figure 2-1 illustrates a Sybase replication system with Oracle data servers. It shows the flow of data between the data servers, through the Mirror Replication Agent, Replication Server, and Enterprise Connect™ Data Access (ECDA) database gateway.
Figure 2-1: Sybase replication system with Oracle data servers
